M2-S | For Ibanez RG etc with Two Pickups - Pickguard Mount

Regular price
£88.00 GBP
Regular price
Sale price
£88.00 GBP
Shipping calculated at checkout.

Flex-Series™ M2-S | For Two Pickup Ibanez RG

  • For: Two Pickup Ibanez RG
  • Mounting: Pickguard Mount Only
  • Switch: 3-Way Blade
  • Volume Control: 250 / 500k Switchable
  • Tone control: - Optional
  • Upgrade Options: Dual Tuned Coil Split (requires compatible pickups)
  • Suits Pickups: Humbuckers / Single Coils / P90s

IMPORTANT: This set uses high-grade, US spec parts. You will need to ream control holes to 9.54mm, and get new US spec 24 spline, or solid 1/4" knobs.


Build Your Harness

FAST SHIPPING

5 YEAR WARRANTY

M2-S | For Ibanez RG etc with Two Pickups - Pickguard Mount

Details

Description

ObsidianWire solderless install logo

Super Easy, Solder-less Install
All Obsidian® Pro-Wired Electronics are super easy to install, and allow for solder-less pickup changes with Obsidian® Plug, Play & Enjoy connectors.

Flex-Series™ | The new generation of Pro-Grade Guitar Wiring

Flex-Series™ M2-S | For Two Pickup Ibanez RG

  • For: Two Pickup Ibanez RG
  • Mounting: Pickguard Mount Only
  • Switch: 3-Way Blade
  • Volume Control: 250 / 500k Switchable
  • Tone control: - Optional
  • Upgrade Options: Dual Tuned Coil Split (requires compatible pickups)
  • Suits Pickups: Humbuckers / Single Coils / P90s

IMPORTANT: This set uses high-grade, US spec parts. You will need to ream control holes to 9.54mm, and get new US spec 24 spline, or solid 1/4" knobs.

Features

ObsidianWire IGNEOS™ Firm Grip Pots

ObsidianWire® IGNEOS™ guitar pots are the new standard for pro-grade guitar wiring.

  • Durable Design - for years of trouble free use
  • Firm Grip Turning - For a solid feel and secure settings
  • Fine Tolerance - Guaranteed to spec +/- 10%

CRYSTAL CLEAR TONE (Treble Bleed)

Retain clarity at lower volumes. To make your tone crystal clear at lower volumes we include an Obsidian® Custom spec treble bleed mod. This prevents tone 'muddiness' at low volumes by allowing high frequencies to pass along a separate path to your amp, rather than being stopped short by the increasing resistance at the volume control.

SMART VOLUME CONTROL (Switchable 250k / 500k)

Easily select between 250k & 500k to optimize the treble balance for your setup

250k = Warmer / balanced treble (great for single coils)
500k = Brighter / retains treble (great for humbuckers & P90s)

MASTER TONE CONTROL (Optional)

Add a custom designed master tone control using our ObsidianWire designed, CTS built IGNEOSpots, for a smooth and useable tone control taper.

Upgrade Options

DUAL TUNED SC (COIL SPLIT)

Turn your humbucker(s) in to a single coil, and back again. To add true versatility to your guitar we build in DUAL TUNED SC, to split your humbucker(s) to a single-coil for lower output, more dynamic tones.

To keep your single coils sound full and vibrant, we use Tuned 'partial split' technology, for higher output sound with fuller mids, than is possible with a full split.

  • Requires split coil compatible humbuckers



Compatibility

Read carefully.

  • Made to fit two pickup Ibanez Rg style control layouts.
  • Pickguard mount only.
  • Requires hole widening to 9.54mm
  • Requires new US spec knobs

Install

  • Short Shaft: Pickguard / Control Plate Mount Only
  • Hole Size: 9.54mm
  • Tone / Volume Hole Spacing: Minimum 57mm (center to center)
  • Knobs: USE ONLY
    -
    Split Shaft 24 Spline Knobs 'US Spec' OR//
    - Solid 1/4" Knobs 'US Spec' with included shaft adapter

DO NOT USE ORIGINAL IBANEZ METRIC / 18 SPLINE KNOBS

Pickups

Switchable Volume Control: 250k / 500k

  • Single Coils - Use 250k
  • Humbuckers -Use 500k
  • P90s  - Use 500k

Does NOT suit Active / Battery powered pickups

Compatible with all M2-S Flex-Series™ Parts

  • Tone Controls
  • Switches
  • Accessories
  • Pro-Wired Jacks

Specs

Install

For install help and other resources please go to our Info Hub.
