ObsidianWire®

A-CPL-TU-C

Custom Universal for Tele® Loaded Control Plate CHROME

Regular price
£117.00 GBP
Regular price
Sale price
£117.00 GBP
Shipping calculated at checkout.

Super Easy, Solder-less Install
Key Features:

  • High Quality Chrome Hardware
  • Traditional 3-Way Tele® switching
  • Built for Humbucker & P90 Loaded Telecasters
  • 4 Optimized Modes (HH, HS, SH & SS)
  • Improves clarity for humbuckers
  • Balances single coils
  • Crystal Clear Tone
  • Smoother Volume & Tone Control
  • Fits Fender® & Squier Telecaster®
  • Includes Pro-Wired Jack


Coil Split Upgrade
  • Hurry, only 1 item left in stock!

FAST SHIPPING

5 YEAR WARRANTY

ObsidianWire solderless install logo

Super Easy, Solder-less Install
All Obsidian® Pro-Wired Electronics are super easy to install, and allow for solder-less pickup changes with Obsidian® Plug, Play & Enjoy connectors.



Your dream loaded Tele® control plate, complete with a set of ObsidianWire® Pro-Wired™ Electronics, and a high quality control plate and knobs.

TELECTASTER® ELECTRONICS FOR HUMBUCKER & P90 LOADED TELES®

We have created this harness especially for humbucker or P90 loaded Telecasters, and made it compatible with single coils, or single coil sized humbuckers as well. We incorporate INTELLIGENT SWITCHING which allows you to get the absolute most out of both pickups, no matter the configuration

INTELLIGENT SWITCHING

Optimized for humbuckers & single-coils When building a Telecaster with a mix of humbuckers and single coils, there is a toss-up between choosing 500k controls, to retain the life of a humbucker, or 250k controls, to balance brighter single coils.

We say 'why choose? '. So we build in Obsidian® Intelligent Switching to give you the absolute best of both your humbuckers and single coils with a wiring harness that will automatically switch between the two.

THE MODES

  • HH Tele® (Humbucker + Humbucker)
  • HS Telecaster (Humbucker Neck + Single Coil Bridge)
  • SH Telecaster (Humbucker Bridge + Single Coil Neck)
  • SS Tele® (Two Single coils / traditional Tele® mode)

CRYSTAL CLEAR TONE (Treble Bleed)

Retain clarity at lower volumes. To make your tone crystal clear at lower volumes we include an Obsidian® Custom spec treble bleed mod. This prevents tone 'muddiness' at low volumes by allowing high frequencies to pass along a separate path to your amp, rather than being stopped short by the increasing resistance at the volume control.

SMOOTH CONTROL

Even tone and volume control all the way from zero to ten. Obsidian® tone and volume controls incorporate carefully selected and custom-built components, as well as our own clever mods to smooth out the taper of your tone and volume controls, so you get a more even roll off all the way from zero to 10.

DUAL SC (COIL SPLIT) - UPGRADE OPTION

Turn your humbuckers in to single coils, and back again. To add true versatility to your guitar we build in Obsidian® Dual SC, allowing you to split each of your humbuckers to singlecoils for lower output, more dynamic tones.

Obsidian® Dual SC is built in to your volume controls using push/pull pots, so no extra mods are required to your guitar.
- Requires split coil compatible humbuckers

Top down view of a Telecaster chrome loaded control plate with chrome knobs. on a clear cut white background
Bottom side view of a Telecaster  loaded control plate with chrome knobs and an ObsidianWire telecaster wiring harness, showing the pots, switches and solderless connector. Set on a clear cut white background
A hand held pre-wired Telecaster control plate with chrome control plate, chrome knobs and a black switch tip.
An artful view of an ObsidianWire telecaster loaded control plate with chrome knobs, chrome plate and a black switch tip. The control plate is set with a blurred grey background.
A pure tone 1/4" pre-wired jack for electric guitar, set on a clear white background.
Custom Universal for Tele® Loaded Control Plate CHROME
A hand held pre-wired Telecaster control plate with chrome control plate, chrome knobs and a black switch tip.

The Custom Universal for Tele® Loaded Control Plate CHROME

  • High Quality Chrome Hardware
  • Traditional 3-Way Tele® switching
  • Built for Humbucker & P90 Loaded Telecasters
  • 4 Optimized Modes (HH, HS, SH & SS)
  • Improves clarity for humbuckers
  • Balances single coils
  • Crystal Clear Tone
  • Smoother Volume & Tone Control
  • Fits Fender® & Squier Telecaster®
  • Includes Pro-Wired Jack

Details

Description

ObsidianWire solderless install logo

Super Easy, Solder-less Install
All Obsidian® Pro-Wired Electronics are super easy to install, and allow for solder-less pickup changes with Obsidian® Plug, Play & Enjoy connectors.



Your dream loaded Tele® control plate, complete with a set of ObsidianWire® Pro-Wired™ Electronics, and a high quality control plate and knobs.

TELECTASTER® ELECTRONICS FOR HUMBUCKER & P90 LOADED TELES®

We have created this harness especially for humbucker or P90 loaded Telecasters, and made it compatible with single coils, or single coil sized humbuckers as well. We incorporate INTELLIGENT SWITCHING which allows you to get the absolute most out of both pickups, no matter the configuration

INTELLIGENT SWITCHING

Optimized for humbuckers & single-coils When building a Telecaster with a mix of humbuckers and single coils, there is a toss-up between choosing 500k controls, to retain the life of a humbucker, or 250k controls, to balance brighter single coils.

We say 'why choose? '. So we build in Obsidian® Intelligent Switching to give you the absolute best of both your humbuckers and single coils with a wiring harness that will automatically switch between the two.

THE MODES

  • HH Tele® (Humbucker + Humbucker)
  • HS Telecaster (Humbucker Neck + Single Coil Bridge)
  • SH Telecaster (Humbucker Bridge + Single Coil Neck)
  • SS Tele® (Two Single coils / traditional Tele® mode)

CRYSTAL CLEAR TONE (Treble Bleed)

Retain clarity at lower volumes. To make your tone crystal clear at lower volumes we include an Obsidian® Custom spec treble bleed mod. This prevents tone 'muddiness' at low volumes by allowing high frequencies to pass along a separate path to your amp, rather than being stopped short by the increasing resistance at the volume control.

SMOOTH CONTROL

Even tone and volume control all the way from zero to ten. Obsidian® tone and volume controls incorporate carefully selected and custom-built components, as well as our own clever mods to smooth out the taper of your tone and volume controls, so you get a more even roll off all the way from zero to 10.

DUAL SC (COIL SPLIT) - UPGRADE OPTION

Turn your humbuckers in to single coils, and back again. To add true versatility to your guitar we build in Obsidian® Dual SC, allowing you to split each of your humbuckers to singlecoils for lower output, more dynamic tones.

Obsidian® Dual SC is built in to your volume controls using push/pull pots, so no extra mods are required to your guitar.
- Requires split coil compatible humbuckers

Specs

MADE IN HOUSE WITH

  • Potentiometers: Obsidian® Custom CTS® Pots 250K (+/-10%) Solid Shaft 1/4"
  • Capacitors: Vintage Plus // 150 Series Polyester Film 0.047UF - (+/-5%) or True Vintage 52' // Radial Metallized Polyester Film (+/-10 %)
  • Switch: Genuine Oak® 3 Way Switch
  • Jack: Pro-Wired Switchcraft® J11 Mono // OR Pure Tone® Mono Multi-Contact 1/4 in

More Info

Compatibility

BUILT TO FIT

  • Fits: Fender® Telecaster® - Right Hand Guitar Only
  • Fits: Squier® Telecaster®
  • Note: Right Hand Guitar Only // Lefty will work but the volume and tone controls will work with an opposite rotation
  • Pickups: Built for humbuckers, P90s and single coils

MAY FIT

  • Other Telecaster style guitars. Check specs below
  • Mounting screw hole spacing = 150mm
  • Minimum Cavity Length = 138mm
  • Minimum Cavity Width = 24mm
  • Minimum Cavity Depth = 35mm

DOES NOT FIT

Does NOT Fit: Thinline telecaster
